Fun in the homelab: Vagrant and ESXi

2020-12-02 19:16:00

It's been a while since I've worked in my homelab, between my day-job and my teaching gig there's just been no time at all. But, with my EX407 around the corner it's time to hammer Ansible home!

Of course, it's tempting to get sidetracked! So when Tomas' Lisenet practice exam for EX407 suggests I need five VMs with RHEL, I go and find a way to build those post-haste. Now that I've been playing with Vagrant more often, that's become a lot easier!

First, there's a dependency: you will need to download and install a recent version of VMware's OVFTool. Make sure that its binary is in your $PATH

After that, JosenK's Vagrant plugin for VMware ESXi makes life so, so easy! On my Linux workstation it was as easy as:

$ sudo apt install vagrant
$ vagrant plugin install vagrant-vmware-esxi
$ mkdir vagrant-first-try; cd vagrant-first-try
$ vagrant init
$ vi Vagrantfile

After which the whole Vagrantfile gets replaced as follows:

nodes = {
   "vagrant1.corp.broehaha.nl" => ["bento/centos-8", 1, 512, 50 ],
   "vagrant2.corp.broehaha.nl" => ["bento/centos-8", 1, 512, 50 ],
   "vagrant3.corp.broehaha.nl" => ["bento/centos-8", 1, 512, 50 ],
   "vagrant4.corp.broehaha.nl" => ["bento/centos-7", 1, 512, 50 ],
   "vagrant5.corp.broehaha.nl" => ["bento/centos-7", 1, 512, 50 ],
}

Vagrant.configure(2) do |config|
  nodes.each do | (name, cfg) |
    box, numvcpus, memory, storage = cfg
    config.vm.define name do |machine|

      machine.vm.box      = box
      machine.vm.hostname = name
machine.vm.synced_folder('.', '/Vagrantfiles', type: 'rsync')
      machine.vm.provider :vmware_esxi do |esxi|
        esxi.esxi_hostname         = '192.168.0.55'
        esxi.esxi_username         = 'root'
        esxi.esxi_password         = 'prompt:'
        esxi.esxi_virtual_network  = "Testbed"
        esxi.guest_numvcpus        = numvcpus
        esxi.guest_memsize         = memory
esxi.guest_autostart = 'true'
        esxi.esxi_disk_store       = '300GB'

      end
    end
  end
end

To explain a few things:

Any requirements? Yup!
